BATTERY BOX
Heavy duty battery box is the innovative solution to turn a battery into a portable power station.
Pre-wired all parts and connnections with design of plug & play setup, making it easy to install and use without any electrical expertise.
Suitable multi-battery types，Lithium, Lead-Acid, AGM, Gel and Calcium batteries, perfect for dual battery system.
Products Categories
Key Features
- High economic power solution
- DC version & AC version(1000w pure sine wave inverter built-in)
- VSR & Solar mppt optional
- Plug & play design
- Multi protections
- Hold-down design for vehicle
- Multi input/output ports
BATTERY BOX Series
Specifications
| Model | DC Battery Box Pro | DC Battery Box Max | AC Battery Box Pro |
| Box Material | ABS+PC UL94 V-0 | ||
| Box Dimension | L420 x W240 x H340mm | ||
| Max Battery Dimension | L330 x W180 x H240mm | ||
| Weight | 3.8kg | 4.1kg | 5.3kg |
| Max.Battery Weight | 35.0kg | ||
| Suitable Battery Type | Lithium(LiFePO4), AGM, Gel, Calcium, Wet | ||
| DC Port | 4 x DC 50A Anderson plug | 4 x DC 50A Anderson plug | 1 x DC 50A Anderson plug |
| 1 x DC 175A Anderson plug | 1 x DC 175A Anderson plug | 1 x DC 175A Anderson plug | |
| 2 x PD & QC 3.0 | 2 x PD & QC 3.0 | 2 x PD & QC 3.0 | |
| 3 x DC 12V 10A Cig socket | 1 x DC 12V 10A Cig socket | 1 x DC 12V 10A Cig socket | |
| 1 x Wireless output(max.15W) | 1 x Wireless output(max.15W) | 1 x Wireless output(max.15W) | |
| / | 1 x DC 10A Solar Input(max. 45V) | ||
| AC Port | / | 2 x AC socket(max.1000W) | |
| Charging Method | AC Charger, Solar, In-vehicle via 50A Anderson plug | ||
| Operating Temperature | -10°C~+60°C | ||
| Humidity | 5%~95% | ||
| APP(IOS & Android) | / | Via Bluetooth | / |
| Alarm | / | Capacity, Voltage | / |
| Cooling Method | Natural Heat Dissipation | Fans | |
| Protection Degree | IP64 | IP20 | |
| Certificate | CE, RoHS, FCC | ||
